25/10-Ton 2-Stage Air/Hydraulic Axle Jack

546SD
Learn more about AFF

The AFF® Super Duty 2- and 3-stage axle jacks cover a wide variety of demands from the trucking agriculture fleet and military sectors. Extra-long handles provide easy under-vehicle access. Each jack is designed for applications where extra capacity or height is required.

  • Descent metering valve allows for a safe and controlled lowering of the load
  • Extra-long handle provides easy positioning under lift points
  • Industrial style casters are ideal for shop or roadside environments
  • Double polished chrome pistons provide tighter tolerances and greater hydraulic seal
  • Safety overload system provides added operator safety
  • Technical Specifications

Capacity (T) - Stage 125
Capacity (T) - Stage 210
Duty LevelSuper Heavy Duty
High Height (in.) - Stage 111.10"/16.85"
High Height (in.) - Stage 214.84"/20.59"
OperationAir/Hydraulic
TypeAxle Jacks
Low Height (in.)7.28
Ram Lift (in.) - Stage 13.82"
Ram Lift (in.) - Stage 27.56"
Extension (in.)1.75" & 3"
Weight (lb.)128
Working Air Pressure116/174
Country Of OriginChina
