30/15-Ton 2-Stage Air/Hydraulic Axle Jack

545SD
Learn more about AFF

The AFF® Super Duty 2- and 3-stage axle jacks cover a wide variety of demands from the trucking, agriculture, fleet, and military sectors. Extra-long handles provide easy under-vehicle access. Each jack is designed for applications where extra capacity or height is required.

  • Descent metering valve allows for a safe and controlled lowering of the load
  • Extra-long handle provides easy positioning under lift points
  • Industrial style casters are ideal for shop or roadside environments
  • Double polished chrome pistons provide tighter tolerances and greater hydraulic seal
  • Safety overload system provides added operator safety
  • Technical Specifications
  • Resources

Capacity (T) - Stage 130
Capacity (T) - Stage 215
Duty LevelSuper Heavy Duty
Handle Length (in.)54"
High Height (in.) - Stage 18.8"/14.5"
High Height (in.) - Stage 211.5"/17.25"
OperationAir/Hydraulic
TypeAxle Jacks
Low Height (in.)5.92
Ram Lift (in.) - Stage 12.91"
Ram Lift (in.) - Stage 25.59"
Extension (in.)1.75" & 3"
Weight (lb.)77
Working Air Pressure116-145
Country Of OriginChina
